Brief Description
Cross Section Calc” is an application that allows you to easily calculate cross-sectional performance (cross-sectional area, cross-sectional secondary moment, cross-sectional modulus, neutral axis position, etc.) for typical cross-sectional shapes.
Detailed Description
Features of this application
- Typical cross-sectional shapes are displayed as icons, and the cross-sectional shape to be calculated can be selected by simply tapping.
- Twenty-seven different cross-sectional shapes are supported, including rectangular, circular, I-shaped, H-shaped, and T-shaped cross sections.
- Cross-sections with any combination of rectangles are also supported.
- Includes a function for saving calculated cross sections.
- By entering dimensions, cross-sectional area, cross-sectional secondary moment, section modulus, and neutral axis position can be calculated.
- Output units can be selected from mm, cm, and m.
how to use
- Tap the icon on the first screen to select the cross-sectional shape.
- Enter the required dimensions according to the selected geometry.
- The calculation is performed immediately and the results are displayed. The unit of measure for the results is selectable.
- If you name and save the file, you can recall it at any time from the My List on the first screen.
Disclaimer
The calculation results and information provided in this application have been carefully prepared, but we do not compensate for their accuracy, completeness, or suitability. We are not responsible for any damages or losses resulting from the results obtained using this application. If you need accurate results, please consult a specialist.
